APPENDIX B: SPECIFICATIONS
26
Current Draw
Idle 0.6 A rms (230 V AC)
Maximum Long-Term Continuous 6.0 A rms (230 V AC)
Burst 8.0 A rms (230 V AC)
Maximum Instantaneous Peak 24 A peak (230 V AC)
Inrush <15 A peak (230 V AC)
PHYSICAL
Enclosure Multi-ply hardwood
Finish Black textured
Protective Grille Hex-stamped steel with acoustical black mesh
Rigging Endframes with captive GuideALinks (0.0 to 5.0-degree splay angles), quick-release pins,
and detachable side handles
Dimensions 44.42 inches (1128 mm) W 17.85 inches (453 mm) H 23.00 inches (584 mm) D
Weight 265 lbs (120.2 kg)
ENVIRONMENTAL
Operating Temperature 0° C to +45° C
Non Operating Temperature –40° C to +75° C
Humidity To 95% at 45° C (non-condensing)
Operating Altitude To 5,000 m (16,404 ft)
Non Operating Altitude To 12,000 m (39,000 ft)
Shock 30 g 11 msec half-sine on each of 6 sides
Vibration 10 Hz – 55 Hz (0.010 m peak-to-peak excursion)
LEO-M Specifications
