15
CHAPTER 4: QUICKFLY RIGGING
IMPORTANT SAFETY CONSIDERATIONS!
When installing Meyer Sound loudspeakers and subwoofers, the following precautions should always be observed:
■ All Meyer Sound products must be used in accordance
with local, state, federal, and industry regulations. It is
the owner’s and user’s responsibility to evaluate the reli-
ability of any rigging method for their application. Rigging
should only be carried out by experienced professionals.
■ Use mounting and rigging hardware that has been rated
to meet or exceed the weight being hung.
■ Make sure to attach mounting hardware to the building’s
structural components (roof truss), and not just to the
wall surface.
■ Make sure bolts and eyebolts are tightened securely.
Meyer Sound recommends using Loctite
®
on all
threaded fasteners.
■ Inspect mounting and rigging hardware regularly. Imme-
diately replace any worn or damaged components.
LEO-M RIGGING OPTIONS
Table 1 summarizes the available rigging options for LEO-M. For complete information on rigging hardware, including
dimensions, weight, configuration, and load ratings, refer to the MTG-LEO-M Assembly Guide (PN 05.215.049.01) available
at www.meyersound.com
.
NOTE: The MCF-LEO-M caster frame and MTF-LEO-M/MICA transition frame do not include quick-release
pins because they are secured with the quick-release pins included with the loudspeakers.
Table 1: LEO-M Rigging Options
Model Weight Features Required Quick-
Release Pins
Required
Shackles
MTG-LEO-M top grid
(PN 40.215.114.01)
205 lbs
(93.0 kg)
With some restrictions, flies up to 22 LEO-Ms at a 5:1
safety factor, or up to 18 LEO-Ms at a 7:1 safety factor;
accommodates a variety of pickup configurations with six
pickup points; includes attachment points to accommo-
date brackets and adapters for lasers and inclinometers
1/2 x 1.50-inch (red button),
PN 134.045, qty 4 included
7/8-inch
MVP motor Vee plate
(PN 40.215.184.01)
20 lbs
(9.1 kg)
Fine tunes the horizontal aim of arrays; compatible with
MTG-LEO-M, MTG-LYON, MTG-1100, and MG-
LEOPARD/900 grids
— 3/4-inch or
7/8-inch
MTF-LEO-M/LYON
transition frame
(PN 40.215.250.01)
85 lbs
(38.6 kg)
With some restrictions, flies up to seven LYONs at a 7:1
safety factor below LEO-M arrays for downfill; includes
rear attachment points for pull-back
7/16 x 1.50-inch (red button),
PN 134.051, qty 4 included
5/8-inch
5/16 x 0.875-inch (red button),
PN 134.025, qty 4 included
MTF-LEO-M/MICA
transition frame
(PN 40.215.131.01)
9 lbs
(4.1 kg)
With some restrictions, flies up to eight MICAs at a 7:1
safety factor below LEO-M arrays for downfill
7/16 x 1.50-inch (red button),
PN 134.051, qty 0 included
—
3/8 x 1.125-inch (blue button),
PN 134.021, qty 0 included
PBF-LEO-M
pull-back frame
(PN 40.215.136.01)
16 lbs
(7.3 kg)
Attaches to bottom of LEO-M arrays (to the MTF-
LEO-M/MICA transition frame) and provides pull-back
for extreme array downtilt; can also be used for pull-up
to expand the array’s splay angles during installation so
the blue locking pins can be more easily inserted
1/2 x 1.50-inch (red button),
PN 134.045, qty 2 included
5/8-inch
RPP-LEO-M
rear pull-up plate
(PN 40.215.181.01)
6 lbs
(2.7 kg)
Helps assemble large arrays with wide splay angles by
providing pull-up (with a motor) to expand the array’s
splay angles during installation so the blue locking pins
can be more easily inserted
1/2 x 2.50-inch (blue button),
PN 134.007, qty 2 included
5/8-inch
MCF-LEO-M
caster frame
(PN 40.215.130.01)
110 lbs
(49.9 kg)
Safely transports up to four LEO-M cabinets, making it
easy to assemble and disassemble arrays in blocks of
four cabinets
1/2 x 1.25-inch (blue button),
PN 134.044, qty 0 included
5/8-inch
