APPENDIX A: UP-4XP ACCESSORIES
24
PHOENIX AND EN3 LOUDSPEAKER CABLES
The following Phoenix and EN3 cables are available from Meyer Sound and can be used to connect UP-4XPs to
MPS-488HPs.
NOTE: Bulk cables use Belden 1502R (regular) or Belden 1502P (plenum) cable. Belden 1502 is a composite
cable comprised of two 18 AWG wires for DC power, two 22 AWG wires for balanced audio, and one 24 AWG
wire for audio shield. This single cable can deliver both DC power and balanced audio to loudspeakers at cable runs
of up to 150 feet with only 1 dB of loss in peak SPL. Longer cable runs are possible with heavier gauges for DC
power and separate cables for balanced audio. For more information, see “UP-4XP Current Draw and Cable
Requirements” on page 13.
Phoenix and EN3 Loudspeaker Cables
Part Number Cable Color Coating Length
524.014 Bulk (no connectors) Black Regular 500 ft spool
524.015 Bulk (no connectors) White Plenum 500 ft spool
28.163.009.01 EN3 5-pin female to pigtail Black Regular 10 ft
28.163.009.11 EN3 5-pin female to pigtail White Plenum 10 ft
28.163.009.21 EN3 5-pin female to EN3 5-pin male Black Regular 10 ft
28.163.009.22 20 ft
28.163.009.23 30 ft
28.163.009.24 50 ft
28.163.009.25 100 ft
28.163.009.26 150 ft
28.163.009.31 EN3 5-pin female to EN3 5-pin male White Plenum 10 ft
28.163.009.32 20 ft
28.163.009.33 30 ft
28.163.009.34 50 ft
28.163.009.35 100 ft
28.163.009.36 150 ft
28.163.033.01 Cable coupler EN3 5-pin female-to-male (joins two cables: one with an EN3 5-pin male cable
mount connector to one with an EN3 5-pin female cable mount connector)
28.163.009.41 EN3 5-pin female to Phoenix 5-pin female Black Regular 10 ft
28.163.009.42 20 ft
28.163.009.43 30 ft
28.163.009.44 50 ft
28.163.009.45 100 ft
28.163.009.46 150 ft
28.163.009.51 EN3 5-pin female to Phoenix 5-pin female White Plenum 10 ft
28.163.009.52 20 ft
28.163.009.53 30 ft
28.163.009.54 50 ft
28.163.009.55 100 ft
28.163.033.01 150 ft
