APPENDIX D: UP-4XP SPECIFICATIONS
34
UP-4XP COMPLIANCE
Output Power 500 W total for all three channels
Note: Wattage rating based on the maximum unclipped burst sine-wave rms voltage the amplifier
will produce into the nominal load impedance.
THD, IM TIM <.02%
Load Capacity 4  each low channel, 8  high channel
Cooling Convection
DC POWER
Voltage Requirement 48 V DC
Current Draw Note: At 48 V DC.
Idle Current 0.23 A rms
Maximum Long-Term 
Continuous Current
1.00 A rms
Burst Current 4.05 A rms
Ultimate Short-Term 
Peak Current
4.50 A peak
Inrush Current < 4.0 A peak
PHYSICAL
Enclosure Premium birch plywood
Finish Black textured
Protective Grille Powder-coated, hex-stamped steel with black mesh screen
Rigging Top and bottom plates available with 3/8”-16 or M10 threads
Dimensions 13.84” W x 5.54” H x 5.25”
(352 mm x 141 mm x 133 mm)
Weight 12.2 lbs (5.53 kg)
ENVIRONMENTAL
Operating Temperature 0° C to +45° C
Non Operating Temperature <–40° C or >+75° C
Humidity To 95% at 35° C
Operating Altitude To 4600 m (15,000 ft)
Non operating Altitude To 95% at 35° C
Shock 30 g 11 msec half-sine on each of 6 sides
Vibration 10 Hz – 55 Hz (0.010 m peak-to-peak excursion)
UP-4XP Specifications
(Pending) (Pending)
