APPENDIX D: UP-4XP SPECIFICATIONS
36
MYA-UP4 Mounting Yoke Dimensions
16.64
[423 mm]
10.00
[254 mm]
Ø0.53
[Ø13 mm]
6.62
[168 mm]
16.33
[415 mm]
8.63
[219 mm]
14.86
[377 mm]
1.00
[25 mm]
