Meyer 8720 - Page 33

Model 8720/8865 -33-
KEY PART NO. DESCRIPTION QTY
1 933-3804 Eyebolt, 5/16 x 5" / 4" Thread Length 1
2 925-3823-6 4-Chain Link For Tightener 1
3 929-0003 Extension Spring 1
4 14-0031 2" Bearing 4-Bolt 2
5 925-3777-2 Tighener Extension Arm 1
6 925-3779 Tightener Arm 1
7 851-7510-3Z 3/4-10 x 3" Machine Bolt Zinc 1
8 933-3642 Grease Line, 2nd Reduction Rear Bearing, 60” 1
9 914-3811 2-1/2” Bearing, 4-Bolt 1
10 910-3755 Reduction Sprocket Weldment-Nonshear 1
11 910-3753 Industrial 2nd Reduction Wldmt 1
12 911-0053 #80-102 Roller Chain, 2nd Reduction Chain 1
13 912-0013 2" Nylon Roller Complete 1
13A 912-0013-1 2” Nylon Roller Only 1
13B 912-0013-2 Inner Sleeve 1
14 808-.75-1.25-14 3/4" ID x 1-1/4" OD Machine Bushing 14 Ga. 2
SECOND REDUCTION DRIVE
