Model 8720/8865 -49-
SPINNER GEAR REDUCER - CENTER (1:1) #19-0130
USE FLUID GEAR GREASE ONLY.
DO NOT
USE OIL FOR LUBRICANT.
KEY PART NO. DESCRIPTION
1 19-0029-2 Casting, Machined (Thru Holes)
2 19-0029-1 Casting, Machined (Tapped Holes)
3 19-0029-3 Assy, Pinion Shaft/Gear
4 19-0130-1 Assy, Cross Shaft/Gear
5 19-0029-5 Bearing Cone
6 19-0029-6 Bearing Cup
7 19-0029-7 Bearing Cone
8 19-0029-8 Bearing Cup
9 19-0029-9 Seal 1-3/4"
10 19-0029-10 End Plug, Rubber Cover
11 19-0029-11 Retaining Ring, 1.750
12 19-0016-11 Bolt, 3/8-16 x 2.250 SHCS
13 19-0016-5 Plug, ½ NPT
14 19-0029-14 Bushing, 1/4 NPT to 1/8 NPT
15 55-0107 Plug, Breather
16 19-0029-16 Bearing Cone
