Meyer 8720 - Axle & Wheels, Hi-Float Package; (Standard 8865) (Optional 8720)

Model 8720/8865 -52-
AXLE & WHEELS, HI-FLOAT PACKAGE
(STANDARD 8865) (OPTIONAL 8720)
KEY PART NO. DESCRIPTION QTY
1 75-0213 Hub Assembly
Complete 20,000#
4
2 75-0213-2 Seal 1
3 75-0213-5 Bearing Cone 1
4 75-0213-10 Bearing Cup 1
5 75-0213-3 Bearing Cup 1
6 75-0213-6 Bearing Cone 1
7 75-0213-12 Washer 1
8 75-0213-13 Nut 1
9 75-0213-14 Cotter Pin 1
10 75-0213-7 Hub Cap 1
11 75-0213-9 Lug Nut - Flanged 10
12 75-0213-4 Stud Bolt 10
13 75-0213-1 Hub Only w/Races
& Studs
1
14 75-0213-8 Hub Cap Bolt 4
15 75-0213-11 Hub Cap Gasket 1
KEY PART NO. DESCRIPTION QTY
16 901-3771 LH Tandem Wing
Assembly, Less
Hubs
1
17 901-3770 RH Tandem Wing
Assembly, Less
Hubs
1
18 901-3864-2 Nylon Pivot Sleeve 2
19 901-3773 O-Beam Pivot As
-
sembly
2
20 881-6311-1.5Z 5/8-11x1½”GR8
M.B.
8
21 822-0063-Z 5/8” Split
Lockwasher
8
22 901-3772 Axle Weldment 1
23 75-0271 DW25-26 Wheel 4
24 30-0006 Zerk 1/8" NPT x 90
Degrees
1
25 30-0009 1/8" NPT Coupler 1
26 30-0008 1/8" NPT Nipple 1
