Meyer 8720 - Page 37

Model 8720/8865 -37-
KEY PART NO. DESCRIPTION QTY
1 933-3701 3" Retaining Ring 1
2 910-0100 140B35 Shear Sprocket Assembly 1
2A 831-5618-1.75 9/16-18 x 1-3/4" Allen Head Cap Screw Grade 8 (Prior to Serial
#SI088720/8865287)
AR
831-5618-2.25 9/16-18 x 2-1/4" Allen Head Cap Screw Grade 8 (Prior to Serial
#SI088720/8865287)
AR
831-6318-1.75 5/8-18 x 1-3/4" Allen Head Cap Screw Grade 8 (Serial
#SI088720/8865287 & Later)
AR
2B 884-5618 9/16-18 Top Locknut Grade 8 (Prior to Serial #SI088720/8865287) AR
884-6318 5/8-18 Top Locknut Grade 8 (Serial #SI088720/8865287 & Later) AR
3 911-0065 140-47 Roller Chain 1
4 933-3704 Front Auger Washer Steel 1
5 933-3750 Auger Sprocket Spacer 1-1/2" Long 1
6 913-3701 Nylon Bushing 3" I.D. x 4" O.D. x 3-3/8" Long 1
7 925-3766 Front Bushing Holder Assembly W/Nylon 1
8 933-3626 Grease Line, Right Auger Bushing Holder 1
9 925-3781 Right Auger Chain Tightener Linkage 1
10 29-0009 Tightener Spring 1
11 925-3807-3 Retaining Washer 1
12 815-7510-Z 3/4-10 Nylon Locknut 1
13 925-3783 Tightener Bolt Assembly 1
14 914-3807A 2-1/2" Round 4-Bolt Bearing 1
15 910-3754-HD 3rd Reduction Weldment 1
16 914-3811 2-1/2" Bearing 4-Bolt 1
17 912-0013 2" Nylon Roller Complete 1
17A 912-0013-1 2" Nylon Roller Only 1
17B 912-0013-2 Inner Sleeve 1
18 808-.75-1.25-14 3/4" I.D. x 1-1/4" O.D. Machine Bushing 14 Ga. 2
19 925-3778 Right Auger Tightener Arm Assembly Less Roller 1
20 925-3778-3 3/4-10 x 2-3/4" Machine Bolt Special 1
21 901-3751-11 #120 Tightener Pivot 1
22 933-3641 Grease Line, 2-1/2" Rear Bearing 1
FINAL REDUCTION, RH AUGER DRIVE
