Meyer 8720 - Page 43

Model 8720/8865 -43-
KEY PART NO. DESCRIPTION QTY
1 901-3765 Splash Guard Assy.
45 Degree
2
2 926-3760 3rd Auger Assy. 1
3 933-3703 Bronze Washer 1
4 913-3701 Nylon Bushing 1
5 925-3770 3rd Auger Bushing
Holder W/Nylon
1
6 926-3770 Right Auger Assy. 1
926-3701-2 Front Splined Sleeve 1
926-3701-2-1 Rear Splined Sleeve
W/Cap Washer
1
926-3750-3 Front Seal Collar 1
926-3770-2 Flighting Gusset 2
926-3771-1 3/8" Right Hand Sec
-
tional Flighting
AR
926-3771-2 Right Auger Knife 1
7 914-3812- NSM Front Auger Thrust
Bearing
2
8 914-3813 Front Auger Thrust
Bearing Seal
2
9 926-3701-1 Splined Auger Shaft
23 Tooth 3" Diameter
2
10 933-3701 3" Retaining Ring 2
11 926-3771 Left Auger Assy.
926-3701-2 Front Splined Sleeve 1
926-3701-2-1 Rear Splined Sleeve
W/Cap Washer
1
926-3750-3 Front Seal Collar 1
926-3770-2 Flighting Gusset 2
926-3770-1 3/8" Leftt Hand Sec-
tional Flighting
AR
926-3770-5 Left Auger Knife 1
12 32-0027-1 Upper T-Latch Bracket 1
13 925-3771-9 Nylon Bearing (2-Per
Auger)
4
14 925-3773 Auger Holdown Assy.
W/Nylon
1
15 925-3771-4 T-Post Holdown Bot
-
tom Collar
1
16 881-1008-5Z 1-08 x 5" Grade 8 Ma
-
chine Bolt
1
17 884-1008 1-08 Grade 8 Top
Locknut
1
18 924-3755 Rear Side Shield 1
19 924-3754 Front Side Shield 1
20 914-3814 2-Bolt 1-1/2" Bearing 5
21 914-3804 1-1/2" Pillow Block
Bearing
1
22 924-3753 Front Cover Assembly 1
23 924-3756 Right Front Shield As
-
sembly
1
24 32-0027-2 Rubber T-Latch 1
25 32-0027-3 Lower T-Latch Bracket 1
26 924-3757 8865 Left Front Sup
-
port Plate
1
27 924-3758-1 Center Shaft Shield 1
28 925-3775-1 PTO Holder Bracket 1
29 901-3757 Bolt On Swivel Hitch
Assembly
1
29A 881-1014-2.5Z 1-14x2-1/2" Grade 8
Machine Bolt
4
KEY PART NO. DESCRIPTION QTY
29B 884-1014-Z 1-14 Top Locknut
Grade 8
4
30 956-3702-1 Jack 1
30A 956-3702-2 Jack Mount Tube 1
30B 956-3702-1-1 Pin & Chain Assy. 1
30C 956-3702-1-3 Screw Nut/Bearing
Washer Kit
1
30D 956-3702-1-2 Gear Bushing Pin Re
-
pair Kit
1
31 33-0044 Manual Holder W/Cap 1
32 46-7000-1 Gate Indicator Decal 1
33 925-3762 Gate Indicator Assem
-
bly
1
34 925-3765 Indicator Pipe 1
35 955-3701 3/8 x 132" Hyd. Hose 2
36 955-3803 3/8" Black Pipe Tee 1
37 955-3609 3/8" Black Coupler 1
38 955-3755 3/8 x 238" Hyd. Pipe 2
39 955-3605 3/8 x 90* Black Elbow 2
40 955-3756 3/8 x 24" Hyd. Pipe 2
41 955-3825 3/8 x 56" Hyd. Hose 2
42 924-3762 R. Lower Auger
Sprocket Shield Assy.
1
43 924-3763 L. Lower Auger
Sprocket Shield Assy.
1
44 925-3750 Front Outer Plate
Assy.
1
925-3750-TR Front Outer Plate
Assy. Truck Mount
1
45 901-3751 Main Body 1
46 933-3647 Grease Line 3rd Auger
Rear Bearing
1
47 929-3801 Hydraulic Hose Holder
Spring
1
48 823-.25-5Z 1/4x5” Hair Pin 4
49 933-3704 Steel Washer 1
50 931-3810 PTO Guard Assy. 1
51 937-0004 1-1/2" Shaft Coupler 1
52 35-0022 3/8 x 3/8 x 4-1/2" Key 1
53 55-0013 Male Pioneer Tip 2
54 955-3703 Gas Lift Assist Spring 1
55 923-3754 Front Side Shaft 1
56 923-3704 Rear Side Shaft 1
57 924-3752 Right Hand Front
Cover
1
58 933-3602 Hydraulic Pipe Bracket 5
59 933-3753 Shaft Collar 2-1/2" 1
60 933-3801 Bronze Washer 2-1/2" 1
61 933-3802 Steel Washer 2-5/8" 1
62 925-3774 Mirror Bracket 1
63 56-0029 Mirror 1
BODY, SHIELDS & AUGERS - 8865 SPREADER
