Parts indented are included in the carton, bag or assembly under which they are indented.
(3)
Black Iron Parts List
* Note that the Truck Side Wiring Harness (55) has changed from a 7 pin to 4 pin as of October
2017. Please use the applicable part number as needed.
** Note that the Trailer Adapter Harness 23057 is used for most vehicles and is included with the
black iron kit.
See Service Bulletin SB 259 for more information.
Item Part # QTY Description
41090 1 DP5.0- 7.5 E-73 DP Mount Assy.
N/A 1 DP6.8-7.5 E-73 DP Mount Assy.
1 05888 1 • Lift Ram 1-1/2 x 8”
07772 1 • LH Ram with Hose & Fittings
2 05887 1 •• Ram (1-1/2” x 10”)
3 22866 1 •• SAE 6 x 90 Degree Elbow
4 22885 1 •• Hose Assy 1/4 x 54” M-6
07783 1 • RH Ram with Hose & Fittings
2 05887 1 •• Ram (1-1/2” x 10”)
3 22866 1 •• SAE 6 x 90 Degree Elbow
4 22921 1 •• Hose Assy 1/4 x 38” M-6
5 10514 1 • Lift Arm
6 14250 1 • Pivot Bar Drive Pro 6.8
7 14185 1 • E-73 DP Mounting Bracket
8 14232 1 • A-Frame Drive Pro
9 14289 1 • E-73 Lift Unit Cover Front
9a 14288 1 • E-73 Lift Unit Cover Rear
10 14290 2 • Lift Unit Cover Bracket
11 16027 1 • E-73 Lift Ass’y. (Unit only)
12 19836 1 • Clevis Drive Pro
18944 1 • Lift Frame Assy DP
13 18919 1 •• Lift Frame
14 19775 2 •• Pin
15 18938 1 •• Pull Pin
16 20406 1 •• Cotter Pin 3/16 x 1-1/2”
17 22010 2 •• Bolt H 3/8-16 x 1-1/4”
18 22260 2 •• Poly Washer 3/8”
19 814000005 1 •• Spring
20 20144 2 • Bolt H 5/8 - 11 x 2-3/4” Gr. 5
21 20147 4 • Bolt H 5/8 - 11 x 3-1/2” Gr. 5
22 20309 5 • Locknut 5/8 - 11
23 20331 2 • Lockwasher 5/8
24 20357 3 • Flatwasher 5/8”
25 20355 2 • Flatwasher 1/2”
26 20385 3 • Cotter Pin 1/8 x 1-1/4”
26a 22845 1 • Hair Pin
27 20420 2 • Cotter Pin 1/4 x 2”
28 22000 1 • Bolt H 5/8-11 x 4-1/2” Gr. 8
29 22022 1 • Crankstand
30 22436 2 • Pin 1 x 3”
31 23039 1 • Plow Side Harness
32 22719 3 • Pivot Pin 5/8 x 3”
33 22866 1 • SAE Mx3/8 90 Degree Elbow
34 22884 1 • Hose 1/4 x 33”
35 20027 4 • Bolt H 5/16-18 x 1” Gr. 2
36 20049 4 • Bolt H 3/8-16 x 1 Gr. 2
37 20100 2 • Bolt H 1/2-13 x 2-3/4” Gr. 5
38 20305 4 • Locknut 3/8-16
Item Part # QTY Description
39 20307 2 • Locknut 1/2-13
40 20530 4 • 5/8-11 Finish Nut
41 22379 4 • Lockwasher 3/8
42 20800 1 • Quick Link 5/16”
43 21543 1 • Chain 5/16” x 29”
41092 1 • Accessory Box
44 23025 1 •• Power Cable - 36”
45 12978 2 •• Trip Spring
07810 1 •• Nite Saber III Kit
09917 1 •• Plow Marker Kit
46 8214 2 ••• Plow Marker
47 20027 4 ••• Bolt H 5/16-18 x 1 Gr. 2
48 20304 4 ••• Locknut 5/16-18
49 20352 8 ••• Flatwasher 5/16”
50 15372 1 •• Starter Solenoid - 12 volt
51 21832 1 •• Split Bushing
52 N/A N/A N/A
53 N/A N/A N/A
54 23047 1 •• Controller
55 23059 1 •• Truck Side Harness (4 Pin)*
23058 1 •• Truck Side Harness (7 Pin)*
41102 1 •• Hardware Bag
56 09124 2 ••• Eye Bolt
57 20357 2 ••• Flatwasher 5/8”
58 20385 2 ••• Cotter Pin 1/8 x 1-1/4”
59 22720 2 ••• Pivot Pin 5/8 x 7
60 15187 1 • Breather
** 23057 1 • Trailer Adapter Harness**
