Meyer EZ Build E-58H 41150 - Table of Contents; General Information

Table of Contents
General Information ............................................................................................................................................................................. 1
Illustrated Parts Lists ..........................................................................................................................................................................2-4
Attaching Plow to EZ Build Assembly ............................................................................................................................................. 5
Vehicle Side Wiring Diagram.............................................................................................................................................................. 6
Drop Speed Adjustment ..................................................................................................................................................................... 7
Stop Bolt Adjustment ........................................................................................................................................................................... 7
Mount Plow System To Vehicle ......................................................................................................................................................... 8
Dis-Mount Plow System From Vehicle ............................................................................................................................................ 9
Pre-Delivery Inspection ..................................................................................................................................................................... 10
Accessories ..............................................................................................................................................................................................11
Web Based Support
(1)
GENERAL INFORMATION
Always disconnect battery prior to installation.
SAFETY PRECAUTIONS should be used when Quik Lift
®
is in a RAISED position.
LOWER plow to the ground when vehicle is PARKED.
OVERHAUL and SERVICE information is covered on separate instructions.
Lift arm should be removed from vehicle if / when snowplow is removed.
Note:
1. Connect ground cable to negative side of battery for a solid connection to ground.
2. Route all cables away from moving engine parts, Manifolds, and sharp sheet metal.
3. For weather protection, coat all connections with Meyer Dielectric Grease Part No. 15632
4. The vehicle must be equipped with a “Heavy Duty Battery” (70 Amp, Hr. Min.), 550 C.C.A. and “Alternator” (60 Amp. Min.) to obtain maximum performance.
5 . F o ll o w t h e s e i n s t r u c t i o n s e x p l i c i t l y. Wa r r a n t y d o e s n o t a p p l y to a M e y e r p r o d u c t w h i c h h a s b e e n n e g l i g e nt l y o r i m p r o p e r l y a s s e m b l e d o r i n s t a l l e d .
Please check the contents of your crate. Page 2 shows the assembled parts in the left hand
column and the accessory box in the right hand column. Page 3 is the diagram for the left
hand column of page 2.
Bolt Nut Size Gr. 2 Gr. 5 Gr. 8
1/4 - 20 4 - 5
5/16 - 18 9 - 11
3/8 - 16 17 - 20 26 - 29
7/16 - 14 42 - 46 60 - 66
1/2 -13 64 - 72 90 - 100
5/8 - 11 127 - 141 179 - 198
TORQUE CHART FOOT POUNDS ADDITIONAL BATTERY CONNECTIONS
1. When attaching cables to battery with side post terminals, use M.P. Adaptor Part #21976.
2. Coat battery connections with battery terminal coating.
http://www.meyerproducts.com/
TechSupport/ServiceManualsandIn-
stallationInstructions.aspx
http://www.meyerproducts.com/
techsupport/EZtroubleshooter.aspx
http://www.meyerproducts.com/
TechSupport/OwnersManuals.aspx
http://www.youtube.com/playlist?list
=PLDE0602B305314D92&feature=e
dit_ok
Service Manuals EZ-Troubleshooter Owners Manual Mount/Dismount Videos
Please visit our website to nd our most updated technical information.
Tool list for Plow assembly:
Pliers
1/2" socket
1/2" box wrench
9/16" box wrench
9/16" socket
3/4" box wrench
15/16" box wrench
15/16" deep well socket
