E-73 Wire and Hose Locations
“A” Valve Black & Black
with White Stripe
“B” Valve Red & Black
with White Stripe
“C” Valve Green & Black
with White Stripe
Left Angle Cylinder
Right Angle Cylinder
Lift Cylinder
Motor Solenoid White
Motor Solenoid Purple
E-73 Drop Speed Adjustment: Loosen jam nut and turn knob clockwise to slow the drop of the plow and
counter clockwise to speed the drop of the plow. Tighten jam nut.
E-73 Drop Speed Adjustment
Drop Speed Adjustment
To Plow Lights
To Vehicle Harness
Purple, Blue, and Yellow
wire sets are not used
To Next Page
