MFJ-974/974H Balanced Line Antenna Tuner Instruction Manual
9
Suggested Tuning Chart
Frequency (MHz) Antenna Inductance Transmitter Load
1.8 0 L 2 25
1.8 0 B 0 50
1.8 2 L 0 600
2.0 2.5 L 3.5 25
2.0 4 B 3 50
2.0 4 L 2.5 600
3.5 2 E 3.5 25
3.5 0 E 0 50
3.5 0 E 0 600
3.75 1.5 E 3 25
3.75 2 E 2 50
3.75 2 E 1.5 600
4.0 0 F 0 25
4.0 1 F 0 50
4.0 1 F 1 600
7.15 0 I 2.5 25
7.15 1 I 0 50
7.15 1.5 I 1.5 600
10.1 0 K 2.5 25
10.1 1 K 0 50
10.1 0 K 1 600
14.2 3 L 4 25
14.2 4 L 3 50
14.2 4 L 3 600
18.1 6.5 L 7.5 25
18.1 6 L 6 50
18.1 7 L 7 600
21.2 7.5 L 7.5 25
21.2 7.5 L 7.5 50
21.2 7 L 7.5 600
24.9 8.5 L 8.5 25
24.9 8.5 L 8.5 50
24.9 9 K 8 600
28.5 8.5 L 9 25
28.5 9 L 9 50
28.5 8.5 L 8 600
50.1 7.5 A 2.5 25
50.1 7 A 6.5 50
50.1 7 B 8.5 600
