R8-PC4A
EM-9795 Rev.4 P. 6 / 6
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
WIRING INSTRUCTIONS
■ e-CON connector
Unit side connector: XN2D-1474-S002 (Omron)
Recommended cable side connector: XN2A-1470 (Omron)*
1
Applicable wire size: 0.08 to 0.5 mm
2
(AWG28 to 20)
Outer sheath diameter: max. 1.5 dia
*1. The cable side connector is not included in the package.
Refer to the specifications of the product.
