The underslung chassis frame is of unusual design having an extrem'ely
low centre of gravity, the main principles of which having already heen tested
and
hrought to perfection in conipctition work and r:icing.
I'igure
2
is
n
rear clid view of the chassis and shows the back axle attached
to the springs by long
"
U
"
holts and a spacer, the mounting of the shock
absorbers, the rear cover to the hack axle with its filler cap, and the cradle for
the battery. The rear cross member has extensions on either side in which
the rear end of the rear springs are located. The Petrol tank is, in point
of fact, actually supported in the Body. The two petrol feed pipes coupling
up to the main and reserve supplies are shown.
PETROL
PIPES
Illustration
No.
3
shows the location of the petrol tank in relation to
the pipe lines, but as before mentioned the petrol tank is actually mounted
in the Body itself.
