Dismantle the A-pillar, as seen in the diagram, and
place the cables into the rubber molding.
For a clean installation, conceal the cables by
tucking them into the gap between the windshield
and headliner as seen in the diagram.
1 2
Place the device on the windshield as seen in the
diagram and then clean the installation area.
Remove the cover off the adhesive mount on the
bracket and mount the product (with the bracket) to
the windshield.
Connect the two cables from the T-Box and the
main body.
