22
Connections
Connect the power cables 7 to the two
electrical sources (S1 and S2) supplying
Pulsar STS.
Connection to UPSs
Connect the power cables 7 to one of the
output sockets on each UPS.
Pulsar STS is energized as soon as one of
the sources (S1 or S2) is in operation.
Fig. 6
to the sensitive
equipment supplied
by Pulsar STS
Pulsar STS 10A
8
Basic
T 6.3A
250V~
Ue/In/Eing
Amp: 25A
Volt: 38Vdc
I max 4.3A
Us/Out/Ausg
UPS S2
Basic
T 6.3A
250V~
Ue/In/Eing
Amp: 25A
Volt: 38Vdc
I max 4.3A
Us/Out/Ausg
UPS S1
8
7
S2 S1
