13
Part Description Qty Part Description Qty
1 Horizontal beam 2 31 Support bar 1
2 Front leg 1 32 M8 x 65mm Bolt 1
3 Front frame 1 33 M8 x 65mm Carriage bolt 1
4 Rear frame 1 34 M8 Nylon locknut 2
5 Backrest tube 2
6 Backrest support bar 1
7 Weight holder 1
8 Foam roller post 1
9 Seat 1
10 Backrest 1
11 Foam roller 2
12 Curl attachment tube 1
13 Curl pad 1
14 M10 x 135mm Bolt 1
15 M10 x 50mm Bolt 4
16 M10 x 65mm Bolt 3
17 M10 x 20mm Bolt 3
18 M8 x 15mm Bolt 2
19 M6 x 38mm Bolt 4
20 M6 x 15mm Bolt 4
21 M10 Nylon locknut 8
22 M10 Washer 19
23 M8 Washer 5
24 Pop pin 1
25 Knob bolt M10 x 55mm 1
26 25mm Large round inner cap 2
27 30x70mm Oval end cap 4
28 50x38mm Square plastic bushing 1
29 25mm Square inner cap 4
30 60x50mm Square plastic bushing 2
Exploded Parts Diagram List
