MH Men'sHealth Active+ - Assembly Instructions; Step 1: Frame Assembly; Step 2: Beam Connection; Step 3: Leg Attachment

5
Assembly Instructions
Slide Weight holder (7)
onto the Rear frame (4).
Then attach Front frame
(3) to Rear frame (4)
with two M10 x 65mm
Bolt (16), four M10
Washers (22), and two
M10 Nylon locknuts (21).
Insert a Pop pin (24)
through the upper hole
to lock the Weight holder
(7) in position.
Step 1
Connect the Rear frame
(4) to the Horizontal
beam (1) and secure in
place using two M10 x
50mm Bolts (15), four
M10 Washers (22), and
two M10 Nylon locknuts
(21).
Step 2
Fit the Horizontal beam
(1) to the Front leg (2)
using two M10 x 50mm
Bolts (15), four M10
Washers (22), and two
M10 Nylon locknuts (21).
Step 3
This product weighs
about 16kg and occupies
a space of approximately
135cm x 43cm when fully
assembled.
