MH Men'sHealth Active+ - Step 4: Leg and Support Bar; Step 5: Backrest Support; Step 6: Backrest Installation

6
Assembly Instructions
Attach Front leg (2) to
Front frame (3) with three
M10 x 20mm Bolt (17),
and three M10 Washer
(22). Connect the
Support bar (31) to the
Front leg (2) and Front
frame (3) , Secure in
place using the M8 x
65mm Carriage bolt (33),
M8 Washer (23), and M8
Nylon locknut (34). And
using the M8 x 65mm
Bolt (32), M8 Washer
(23), and M8 Nylon
locknut (34).
Step 4
Fit the 2 x Backrest tubes
(5) to the left and right
side of Front frame (3)
with one M10 x 135mm
Bolt (14), two M10
Washers (22), and one
M10 Nylon locknut (21).
Attach the Backrest
support bar (6) in
between the two
Backrest tubes (5), and
Weight holder (7).
Secure them with one
M10 x 65mm Bolt (16),
two M10 Washers (22),
and one M10 Nylon
locknut (21).
Step 5
Place the Backrest (10)
onto the Backrest tubes
(5). Secure it with four M6
x 38mm Bolts (19).
Step 6
