MH Men'sHealth Active+ - Step 7: Seat and Rollers; Step 8: Curl Attachment

7
Assembly Instructions
Place the Seat (9) onto
the Front frame (3).
Secure it with four M6 x
15mm Bolts (20). Insert
Foam roller post (8)
onto Front leg (2). Slide
foam rollers (11) onto
either side of foam roller
post (8). Slide 25mm
large round inner caps
(26) onto either end of
the foam roller post (8).
Step 7
Place the Curl pad (13)
onto the Curl attachment
tube (12). Secure it with
two M8 x 15mm Bolts
(18) and two M8
Washers (23). Place the
Curl attachment tube
(12) onto the Front leg
(2). Insert a Knob bolt
M10 x 55 (25) through
the hole to lock the Curl
attachment tube (12) in
position.
Step 8
