Procon
. S T .
Typical single Procon , , & boiler installation serving two heating zones and domestic hot water (pri-
ority) with individual charging pumps, using a low velocity mixing header. AGU. Clip-In Module required.
Please note;
• The Procon, & models include an internal pump and therefore an external boiler pumpis
not required.
• The boiler pump on the Procon must be wired to K (Terminals X-)
Fig .a – Hydraulic Layout
Fig .b – Wiring Diagram for Models , &
Legend
C External Controller, either
QAA Room Unit, or Volt
Free Enable
OS Outside Air Sensor (QAC)
SV Safety Valve
IV Isolation Valve
LSV Lockable Service Valve
S/T Hot Water Sensor (QAZ), or
Volt Free Enable
CWM Cold Water Main DOC Drain
O Cock
Notes
* Only t one type of Room
Temperature Control.
* Parameter Change may be
required.
* Heating Zone
* Heating Zone , via AGU.
Clip-In Module.
