T1-31
Subject to technical changes, edition 03.2008
MHZ carrier bar awning CLASSIC
*Advice: for orders without details of installation substructure you will receive brackets for the installation on concrete C20/25. Please consider the
respective extraction forces depending on the installation substructure and the bracket set. Other installation substructure, as well as installation on
insulated plaster is mandatory to be mentioned at order, because other accessories could be necessary (additional charge).
MODEL ILLUSTRATION
order details please use order form for awnings (www.mhz.de)
4
6
5
2
3
1
11. awning fabric
12. side bearing with cover
13.wall bracket (installation on concrete)
14. fabric tube
15. carrier bar
16. arm bracket / adjustment
for angle of inclination
17. joint arm
18. drop bar with end caps
9. valance with binding
8
9
item no.
frame colours
width
projection
fabric no.
Design of valance
colour of valance binding
mode of operation
operation side (seen from outside)
length of crank
installation
installation substructure*
(maybe additional charge)
additional equipment
accessories
7
guide bar PRISMA (additional charge)rain hood (additional charge)
drop valance VERTIMA (add. charge)
light bar (additional charge)
please see page T1-41
additional equipment
