MHZ CLASSIC - Detailed Technical Dimensions; Wall Mounting Dimensions; Ceiling Mounting Dimensions

MHZ carrier bar awning
CLASSIC
T1-32
Subject to technical changes, edition 03.2008
230 mm
260 mm
230 mm
235 mm
TECHNICAL DETAILS
wall installation
standard wall bracket
for installation on concrete
(delivered with awning)
ceiling installation
standard ceiling bracket
for installation on concrete
(additional charge)
If required we will send to you 1:1 drawings of our awning constructions for wall and ceiling installation.
60
20
84
150 mm
96
225 mm
85 49
96
60
85
37
154 mm
230 mm
296 mm
315 mm
wall installation with rain hoodwall installation
ceiling installation
*Please note: for installation on wood wind resistance category 0 is valid. The maximum projection is 300 cm. Please check static
of wooden construction before. Please draw a sketch with position of awning, rafters and the space between. Please ask for form
sheet " measurement of center to center brackets CLASSIC".
rafter bracket*
(accessory)
140
max.
150
160 mm
WK 1
DK 1
