MicaSense RedEdge-MX - Center Wavelengths and Bandwidth; RX02+ Camera Specifications; Imager;Band Number and Output; Band Mapping

November 2020
Page 3 of 21
Pixel size
3.75 μm
Resolution
1280 x 960
(1.2 MP x 5 imagers)
Aspect ratio
4 : 3
Sensor size
4.8 mm x 3.6 mm
Focal length
5.4 mm
Field of view
47.2 degrees horizontal, 35.4 degrees
vertical
Output bit depth
12-bit
GSD @ 120 m (~400 ft)
8 cm/pixel per band
GSD @ 60 m (~200 ft)
4 cm/pixel per band
Center wavelengths and bandwidth
Cameras with serial number RX02 or higher
Name
Center
Bandwidth
Blue
475 nm
32 nm
Green
560 nm
27 nm
Red
668 nm
16 nm
Red edge
717 nm
12 nm
Near infrared
842 nm
57 nm
© 2020 MicaSense, Inc
