MicaSense RedEdge-MX - RX01 Camera Specifications; Imager Numbering; Measurements and Attachment Points; Mounting Holes and Screws

November 2020
Page 4 of 21
Cameras with serial number RX01
Name
Center
Bandwidth
Blue
475 nm
20 nm
Green
560 nm
20 nm
Red
668 nm
10 nm
Red edge
717 nm
10 nm
Near infrared
840 nm
40 nm
Imager/band number and output
1
Blue
2
Green
3
Red
4
NIR
5
Red edge
Measurements and Attachment Points
There are four M3 screw holes at 60 mm x 35 mm on-center. The sensor can be attached to
the host aircraft using at least two of the four provided threaded mounting points and M3 x 0.5
screws. If using only two mounting points, it is important to choose two threaded points
opposite of each other.
