Copyright © 2009-2016 Micca. All rights reserved. Page | 16
5 Specification
5.1 General
PCM Formats: ································· PCM (44.1/48/88.2/96/176.4/192kHz, 16/24bit)
DSD Formats: ·································· DSD64 (2.8MHz), Native or DoP, USB Only
USB Interface: ································· USB 2.0, Asynchronous Transfer Mode
Audio Controller: ······························ VIA VT1736
DAC IC: ·········································· Cirrus Logic CS4392
Output Op-amp: ······························· JRC NJM4556
Channel Imbalance: ·························· < 0.5dB
Optical S/PDIF Format: ······················ PCM Only (No signal when playing DSD)
Power Source: ································· 5V/500mA
Dimensions: ···································· 4.6 x 1.5 x 1.9 Inch (116mm x 38mm x 47mm)
Weight: ··········································· 6 Oz (170g)
5.2 Line Output
Frequency Response: ······················· 20Hz ~ 20kHz +/- 0.1dB
THD+N: ·········································· <0.003% (1kHz, A-wt.)
Signal to Noise Ratio: ························ >110dB (1kHz, A-wt.)
Crosstalk: ······································· >96dB (1kHz)
Output Voltage: ································ 5.6Vrms (Gain: 0dB); 1.7Vrms (Gain: -10dB)
5.3 Headphone Output
Frequency Response: ······················· 20Hz ~ 20kHz +/- 0.1dB
THD+N: ·········································· <0.003% (1kHz, A-wt.)
Signal to Noise Ratio: ························ >110dB (1kHz, A-wt.)
Crosstalk: ······································· >96dB (1kHz)
Output Voltage: ································ 5.6Vrms (Gain: 0dB); 1.7Vrms (Gain: -10dB)
Output Current: ································ 70mA (Nominal); 100mA (Max)
Output Impedance: ··························· 0.5 Ω
Load Impedance: ······························ 16 ~ 600 Ω
