A. Power
Only use the supplied AC power adapter to provide 5.0-5.2VDC power to the Micca
Speck. Using a different power adapter may damage the player. Do not cut off power to
the device while the unit is turned on as this may cause serious damage to the hard
drive and result in data loss. Make sure that the player is in standby mode before
disconnecting power. The player consumes a small amount of power in standby and
should be disconnected from power to conserve energy if not planned to use for a while.
B. Analog AV Output
The Micca Speck can be connected to analog TVs and display devices through its AV
Out connector. Only use the supplied 3.5mm-to-RCA cable to ensure correct signal
polarity and avoid damage to the player and TV/display. The RCA cable connectors are
color coded to match the AV input on TVs and display devices as follows:
Composite Video
The Micca Speck’s video output mode must be set to NTSC or PAL for the analog AV
output to function. If there is no picture or the picture is distorted after connecting the AV
Output, press the <AV> button on the remote to set the player’s video output mode to
NTSC. If PAL output mode is needed, use the settings menu to change the player’s
video output mode to PAL.
NTSC is compatible with all TV’s in the US. PAL is used for TVs in
certain countries in Europe, Asia, and others.
C. HDMI Output
The Micca Speck can be connected to HDTVs and digital display devices through its
HDMI connector, sending both audio and video signals over one cable. Only use HDMI
cables that have been certified to be v1.3a or higher to ensure signal quality. The Micca
Speck’s HDMI output resolution can be set to 720p (50/60Hz) and 1080i/p (50/60Hz).
