P341/EN AD/F43 Update Documentation
(AD) -10
MiCOM P341
EU Directives
EMC Compliance
Per 2004/108/EC:
Compliance to the European Commission
Directive on EMC is claimed via the Technical
Construction File route. Product Specific
Standards were used to establish conformity:
EN50263: 2000
Product Safety
Per 2006/95/EC:
Compliance with European Commission Low
Voltage Directive. Compliance is
demonstrated by reference to generic safety
standards:
EN60255-27: 2005
EN60255-5: 2001
2004/108/EC:
R&TTE Compliance
Radio and Telecommunications Terminal
Equipment (R & TTE) directive 95/5/EC.
Compliance demonstrated by compliance to
the Low Voltage Directive, 2006/95/EC:
down to zero volts by reference to safety
standards.
Applicable to rear communications ports.
ATEX Compliance
ATEX Potentially Explosive Atmospheres
directive 94/9/EC, for equipment.
The equipment is compliant with Article 1(2) of
European directive 94/9/EC.
It is approved for operation outside an ATEX
hazardous area. It is however approved for
connection to Increased Safety, “Ex e”, motors
with rated ATEX protection, Equipment
Category 2, to ensure their safe operation in
gas Zones 1 and 2 hazardous areas.
CAUTION - Equipment with this marking is not
itself suitable for operation within a potentially
explosive atmosphere.
Compliance demonstrated by Notified Body
certificates of compliance.
II (2) G
Mechanical Robustness
Vibration Test
Per IEC 60255-21-1: 1996:
Response Class 2
Endurance Class 2
Shock and Bump
Per IEC 60255-21-2: 1996:
Shock response Class 2
Shock withstand Class 1
Bump Class 1
Seismic Test
Per IEC 60255-21-3: 1995:
Class 2
P34x THIRD PARTY COMPLIANCES
(UL/CUL, ENA)
File Number: E202519
Original Issue Date: 05-10-2002
(Complies with Canadian and US
requirements).
Certificate Number: 104 Issue 2
Assessment Date: 16-04-2004
Protection Functions
Reverse/Low Forward/Over Power
Accuracy
Pick-up: Setting 10%
Reverse/Over Power Drop-off:
0.95 of setting 10%
Low forward power Drop-off:
1.05 of setting 10%
Angle variation Pick-up:
Expected pick-up angle 2 degree
Angle variation Drop-off:
Expected drop-off angle 2.5 degree
Operating time: 2% or 50ms whichever is
greater
Repeatability: <5%
Disengagement time: <50ms
tRESET: 5%
Instantaneous operating time: <50ms
