Micom P341 - Measurements List

Update Documentation P341/EN AD/F43
MiCOM P341 (AD) -25
Measurements List
Measurements 1
I Magnitude
I Phase Angle
Per phase (
 = A/A-1, B/B-1, C/C-1) current
measurements
IN Derived Mag
IN Derived Angle
ISen Mag
ISen Angle
I1 Magnitude
I2 Magnitude
I0 Magnitude
I RMS
Per phase (
 = A, B, C) RMS current
measurements
IN -2 Derived
V- Magnitude
V- Phase Angle
V Magnitude
V Phase Angle
All phase-phase and phase-neutral voltages
(
 = A, B, C).
VN Measured Mag
VN Measured Ang
VN Derived Mag
V1 Magnitude
V2 Magnitude
V0 Magnitude
V RMS
All phase-neutral voltages (
 = A, B, C).
Frequency
I1 Magnitude
I1 Angle
I2 Magnitude
I2 Angle
I0 Magnitude
I0 Angle
V1 Magnitude
V1 Angle
V2 Magnitude
V2 Angle
V0 Magnitude
V0 Angle
Measurements 2
 Phase Watts
 Phase VArs
 Phase VA
All phase segregated power measurements,
real, reactive and apparent (
 = A, B, C).
3 Phase Watts
3 Phase VArs
3 Phase VA
NPS Power S2
3Ph Power Factor
Ph Power Factor
Independent power factor measurements for
all three phases (
 = A, B, C).
3Ph WHours Fwd
3Ph WHours Rev
3Ph VArHours Fwd
3Ph VArHours Rev
3Ph W Fix Demand
3Ph VArs Fix Dem
I Fixed Demand
Maximum demand currents measured on a
per phase basis (
 = A, B, C).
3Ph W Roll Dem
3Ph VArs Roll Dem
I Roll Demand
Maximum demand currents measured on a
per phase basis (
 = A, B, C).
3Ph W Peak Dem
3Ph VAr Peak Dem
I Peak Demand
Maximum demand currents measured on a
per phase basis (
 = A, B, C).
Reset Demand: No/Yes
Measurements 3
IREF Diff
A Ph Sen Watts
A Ph Sen VArs
A Phase Power Angle
Thermal Overload
Reset Thermal O/L: No/Yes
CLIO Input 1/2/3/4
Circuit Breaker Monitoring Statistics
CB Operations
Total I Broken
Cumulative breaker interruption duty
on a per phase basis (
 = A, B, C)
CB Operate Time
Reset CB Data: No/Yes.
