P341/EN AD/F43 Update Documentation
(AD) -26
MiCOM P341
APPLICATION NOTES (P341/EN AP/F33)
2.1 Configuration column
The P34x relays include a column in the menu called the “CONFIGURATION” column. This
affects the operation of each of the individual protection functions. The aim of this column is
to allow general configuration of the relay from a single point in the menu. Any of the
functions that are disabled or made invisible from this column do not then appear within the
main relay menu.
The following table shows the relay menu for the Configuration column, with default settings.
The brief description of the function of each setting is also provided.
Menu Text Default Setting Available Settings Function
CONFIGURATION
Restore Defaults No Operation
No Operation
All Settings
Setting Group 1
Setting Group 2
Setting Group 3
Setting Group 4
Restore default
settings to any or all
groups of settings
Setting Group Select via Menu
Select via Menu
Select via PSL
Change setting
groups by
Active Settings Group 1
Group 1
Group 2
Group 3
Group 4
Select active setting
group used for
protection settings
Save Changes No Operation
No Operation
Save
Abort
Saves all setting
changes from stored
settings buffer
memory into stored
settings
Copy From Group 1 Group1, 2, 3 or 4
Selects a group of
settings to copy to
the group designated
in “Copy To” cell
Copy To No Operation Group1, 2, 3 or 4
Copies the group of
settings selected in
the “Copy From” cell
to the selected setting
group
Setting Group 1 Enabled Enabled or Disabled
Selects if Group 1
settings are available
on the relay
Setting Group 2 Disabled Enabled or Disabled
Selects if Group 2
settings are available
on the relay
Setting Group 3 Disabled Enabled or Disabled
Selects if Group 3
settings are available
on the relay
Setting Group 4 Disabled Enabled or Disabled
Selects if Group 4
settings are available
on the relay
System Config Visible Invisible or Visible
Makes settings visible
in the relay
