Update Documentation P341/EN AD/F43
MiCOM P341 (AD) -27
Menu Text Default Setting Available Settings Function
Power Enabled Enabled or Disabled
Makes settings visible
in the relay menu
Thermal Overload Enabled Enabled or Disabled
Makes settings visible
in the relay menu
Overcurrent Enabled Enabled or Disabled
Makes settings visible
in the relay menu
Earth Fault Enabled Enabled or Disabled
Makes settings visible
in the relay menu
SEF/REF/SPower SEF/REF
Disabled or
SEF/REF or
Sensitive Power
Makes settings visible
in the relay menu
Residual O/V NVD Enabled Enabled or Disabled
Makes settings visible
in the relay menu
df/dt Disabled Enabled or Disabled
Makes settings visible
in the relay menu
V Vector Shift Disabled Enabled or Disabled
Makes settings visible
in the relay menu
Reconnect Delay Disabled Enabled or Disabled
Makes settings visible
in the relay menu
Volt Protection Enabled Enabled or Disabled
Makes settings visible
in the relay menu
Freq Protection Enabled Enabled or Disabled
Makes settings visible
in the relay menu
CB Fail Disabled Enabled or Disabled
Makes settings visible
in the relay menu
Supervision Disabled Enabled or Disabled
Makes settings visible
in the relay menu
Input Labels Visible Invisible or Visible
Makes settings visible
in the relay menu
Output Labels Visible Invisible or Visible
Makes settings visible
in the relay menu
CT & VT Ratios Visible Invisible or Visible
Makes settings visible
in the relay menu
Event Recorder Invisible Invisible or Visible
Makes settings visible
in the relay menu
Disturb Recorder Invisible Invisible or Visible
Makes settings visible
in the relay menu
Measure’t Setup Invisible Invisible or Visible
Makes settings visible
in the relay menu
Comms Settings Visible Invisible or Visible
Makes settings visible
in the relay menu
Commission Tests Visible Invisible or Visible
Makes settings visible
in the relay menu
Setting Values Primary
Primary or
Secondary
Selects if relay
protection settings are
displayed in primary
or secondary
current/voltage values
