Micro-Air, Inc. Page 38 EasyTouch 2.5 Operations Manual
Rev 1.0 8/27/14
17. SPECIFICATIONS
OPERATIONAL
Set Point Operating Range (single) .......................................................... 65°F to 85°F (18°C to 30°C)
Set Point Operating Range (dual, cool mode) .......................................... 65°F to 95°F (18°C to 35°C)
Set Point Operating Range (dual, heat mode) ......................................... 55°F to 85°F (13°C to 30°C)
Ambient Temperature Operating Range Displayed ............................... 5°F to 150°F (-15°C to 65°C)
Sensor Accuracy ................................................................................. ± 2°F @ 77°F (±1.0°C @ 25°C)
Low Voltage Processor Reset .................................................................................................. 50 VAC
Line Voltage ................................................................................................................. 100 to 240 VAC
Frequency ........................................................................................................................... 50 or 60 Hz
Fan Output ............................................................................................................ 6 Amps @ 115 VAC
Fan Output ............................................................................................................... Amps @ 230 VAC
Valve Output ................................................................................................. 1/4 Amp @ 115/230 VAC
Heater Output (using valve relay) ....................................................................... 15 Amps @ 115 VAC
Heater Output (using valve relay) ............................................................................ 10 Amps @ 230 V
Pump Output .......................................................................................................... 1/4 HP @ 115 VAC
Pump Output .......................................................................................................... 1/2 HP @ 230 VAC
Compressor Output ................................................................................................... 1 HP @ 115 VAC
Compressor Output ................................................................................................... 2 HP @ 230 VAC
Minimum Operating Temperature ....................................................................................... 0°F (-18°C)
Maximum Ambient Operating Temperature..................................................................... 180°F (82°C)
Maximum Rh Conditions .................................................................................... 99% Non-Condensing
Power Consumption ................................................................................................ Less Than 5 Watts
DIMENSIONS
Display Panel ................................................................................... 4.309” (109mm) X 2.874" (73mm)
Panel Cut Out ......................................................................................2.90" (74mm) X 2.165" (55mm)
Bezel Type Required .................................................................. Vimar® Eikon or Vimar® Eikon EVO
CABLE LENGTHS
Display Cable Self Contained ................................................................................ 15' (4.6m) Standard
Display Cable Split System .................................................................................... 30' (9.1m) Standard
Maximum Display Cable Length ......................................................................... 75' (22.9m) Maximum
Alternate Air Sensor (optional) ................................................................................. 7' (2.1m) Standard
Alternate Air Sensor Split System (optional) ......................................................... 30' (9.1m) Standard
Outside Air Sensor (optional) ................................................................................. 15' (4.6m) Standard
Maximum Temperature Sensor Cable Length .................................................... 75' (22.9m) Maximum
Combo Inside Temperature/Humidity Sensor (optional for FX2 only) ..................... 7' (2.1m) Standard
Maximum Combo Inside Temperature/Humidity Sensor Cable Length ............... 15' (4.6m) Maximum
SYSTEM INPUTS
Inside Air Temperature Sensor (built into display) ............................................................................... 1
High Refrigerant Pressure ................................................................................................................... 1
Low Refrigerant Pressure (optional) .................................................................................................... 1
Alternate Inside Air Temperature Sensor (optional) ............................................................................ 1
Combo Inside Temperature/Humidity Sensor (optional for FX2 only) ................................................. 1
Outside Air Temperature Sensor (optional) ...........................................................................................
Pump Sentry Condenser Coil Sensor (optional) .................................................................................. 1
