7 of 20 IM-5000E-USA Rev A, 2021-01
Accessories
MicroAire 1200-Series Sagittal Saw Blades
MicroAire ZB-Series Burs
MicroAire 1400-Series and ZR-Series Reciprocating Saw Blades and Rasps
MicroAire ZS-3XX Sagittal Blades
MicroAire ZS-Series Sagittal Blades
MicroAire ZO-Series Small Oscillating Blades
MicroAire 8054-Series Standard Twist Drills
MicroAire 8053-Series Synthes-Style Twist Drills
Cleaning Brush (REF 5130-BR)
Drill Chuck Key (REF 1645-004)
Hex Driver (REF 2250-001)
Large Bur Guard (REF 5130-BG-L)
Locking Tool (REF 1745-001)
Medium Bur Guard (REF 5130-BG-M)
5130 Spare Parts Kit (5130-SP)
WARNING: Make sure that the blade is centered between the washer and the locking plate on
REF 5972, and not between just the washer and the locking nut.
WARNING: Where there is a concern about TSE/vCJD contamination, the World Health
Organization recommends processing through a pre-vacuum steam sterilization cycle
for 18 minutes at 134°C (273°F). (WHO/CDS/CSR/2000.3, “WHO Infection Control
Guidelines for TSE,” March 1999).
WARNING: After sterilization, allow instruments to cool to room temperature. Do not use
instruments that are still warm. Do not soak instruments or wrap in wet towels to cool.
SYSTEM COMPONENTS
REF Description
5000ET Electric Motor with Throttle (Handpiece)
5000E Electric Motor without Throttle (Handpiece)
5025 Electric Instrument Console
5006-5000 Instrument Cable 5000-Series to 5020/5025
5401 Series-5000 Electric Foot Pedal
5025-5401 Instrument Cable 5401 Pedal to 5020/5025
5000SC Instruments Sterilization Case 5000-Series
5922 Micro Sagittal Saw Module
5930 30K Micro Drill Module
5945 Reciprocating Saw Module
5950 Hall Style Sagittal Saw Module, Keyless
5955 Hall Style Sagittal Saw Module, with Key
5972 Oscillating Saw Module, with Key
5980 Jacobs Drill Module
5990 AO Drill (Synthes Style (Quick-Connect) Module
