MCP2515 CAN Bus Monitor Demo Board User’s Guide
DS50001757B-page 28 2008-2014 Microchip Technology Inc.
2V
DD
and GND PC TEST POINT COMPACT SMT Keystone Electronics
Corp.
5016
1 U1 PIC18F4550 High-Performance,
Enhanced Flash, USB Microcontroller
with nanoWatt Technology
Microchip Technology
Inc.
PIC18F4550-I/PT
1 U2 Stand-alone Controller Area Network
(CAN) Controller
Microchip Technology
Inc.
MCP2515-I/ST
1 U3 High-Speed CAN Transceiver Microchip Technology
Inc.
MCP2561-I/SN
2 X1, X2 CRYSTAL 20.000 MHz 18 pF FUND
SMD
Abracon® Corporation ABM3B-20.000MHZ-B2-T
1 Mini USB
Cable
Note: This item is packaged with Kit
USB A Male to Mini USB B 5 pin
Cable – 3 ft.
http://ktusasys.stores.yahoo.net/usb-
matomib5p1.html
— KT143-3
TABLE B-1: BILL OF MATERIALS (BOM) (CONTINUED)
Qty Reference Description Manufacturer Part Number
Note: The components listed in this Bill of Materials are representative of the PCB assembly. The
released BOM used in manufacturing uses all RoHS-compliant components.
TABLE B-2: PARTS FOR RIBBON CABLE ASSEMBLY
Qty Reference Description Manufacturer Part Number
1 Cable CABLE 10 COND 100 FT FLAT, GREY 3M/ESD 3365/10(300SF)
2 P2,P3 CONN IDC SKT 10 POS W/POL 15
GOLD
TE Connectivity, Ltd. 1658621-1
2 P2,P3 PULL TAB LOOP 10 POS SOCKET
CONN (P2 P3)
TE Connectivity, Ltd. 88450-2
2 P2,P3 STRAIN RELIEF 10 POS SOCKET
CONN
TE Connectivity, Ltd. 499252-5
1 DB9 Conn CONN DB9 FEMALE PLASTIC SHELL Assmann Electronics
Inc.
A-DFF09LPIII/FP-R
Note: The components listed in this Bill of Materials are representative of the PCB assembly. The
released BOM used in manufacturing uses all RoHS-compliant components.
