Model LV1 Microfluidizer Data Sheet
F-LV-1-5 8/3/2011 LV1 User Manual F-2
Model Number
LV1
Oil Reservoir Capacity (Approximate)
2.5 liters (0.7 gallon)
Motor Horse Power
0.37 kw (1/2 hp)
Motor Data
RPM
Voltage
Amperage
Phase
Frequency
1800 RPM
110V
10A
1 Phase
60 Hz
1800 RPM
208 -
230VAC
5A
1 Phase
60 Hz
1400 RPM
208 to
230VAC
5A
1 Phase
50 Hz
Approximate Unit Dimensions (WxDxH)
51.0 x 65.0 x 60.2 cm
(20.0” x 25.8” x 23.7”)
Approximate Gross Weight (with oil)
109 kg (240 lbs.)
Piston Seal Assembly
UHMWPE & PEEK
Coned and Threaded Fittings Torque
10 Nm (8.5 Ft-lb)
Nitrogen Volume/Charge Pressure for the
Accumulator
1 liter / 96.5 bar (1,400 psi)
Noise level less than 77 dBA.
