Microgate SyncLink - Adapter Cables

Adapter Cables
The card has two high density 26-pin connectors, one for each port. Adapter cables are included with
the card to convert each 26-pin connector into a standard DB-25 male connector. Port 1 is closest to the
PCIe edge connector. Port numbers are labeled on the board and bracket.
Adapter Cables and Port Numbering
Port 2
Port 1
DB-25 Male
HD-26
