Diagnostic Board Overview
Figure 9: Diagnostic Board Overview
Current Sense
Circuit Supply Input
Voltage (9VDC)
9V Battery Holder
Device Input Power
Terminal Block
Rectified AC Power Cell
DC Input Connector
Device/Load
Terminal Block
Blinking LED
Test Circuit
Rectified Power Cell
DC Input Connector
Oscilloscope
Probe Clip Loops
