MHX-920 Operating Manual: Appendix D. Factory Default Settings 51
D. Factory Default Settings
AT&F1 - Master Default Settings
E1, Q0, V1, W0, S0=1, S2=43, S3=13, S4=10, S5=8
DCD &C1 (On)
DTR &D0 (DTR is ignored)
Framing &E0 (Disabled)
Handshaking &K3 (Enabled)
DSR &S1 (On in Data, Off in Command)
Operating Mode S101=1 (Master P-MP)
Serial Baud Rate S102=7 (9600 baud)
Wireless Link Rate S103=2 (Fast, No FEC)
Network Address S104=1
Unit Address S105=1
Primary Hop Pattern S106=0
Encryption Key S107=1
Output Power S108=2 (100mW)
Hop Interval S109=4
Data Format S110=1 (8N1)
Packet Minimum Size S111=1
Packet Maximum Size S112=43
Packet Retransmissions S113=1
Packet Size Control S114=0
Packet Repeat Interval S115=1 (Don’t Care)
Character Timeout (ms) S116=8
Modbus Mode S117=0
Roaming S118=0
Quick Enter to Command S119=1
RTS/DCD Framing (ms) S120=0
DCD Timeout (ms) S121=0
Remote Control S122=0
Secondary Hop Pattern S206=2 (Don’t Care)
Packet Retry Limit S213=2 (Don’t Care)
AT&F2 - Slave Default Settings
E1, Q0, V1, W0, S0=1, S2=43, S3=13, S4=10, S5=8
DCD &C1 (On)
DTR &D0 (DTR is ignored)
Framing &E0 (Disabled)
Handshaking &K3 (Enabled)
DSR &S1 (On in Data, Off in Command)
Operating Mode S101=3 (Slave)
Serial Baud Rate S102=7 (9600 baud)
Wireless Link Rate S103=2 (Fast, No FEC) (Set by Master)
Network Address S104=1
Unit Address S105=2
Primary Hop Pattern S106=0
Encryption Key S107=1
Output Power S108=2 (100mW)
Hop Interval S109=4 (Set by Master)
Data Format S110=1 (8N1)
Packet Minimum Size S111=1
Packet Maximum Size S112=43
Packet Retransmissions S113=1 (Don’t Care)
Packet Size Control S114=0
Packet Repeat Interval S115=1
Character Timeout (ms) S116=8
Modbus Mode S117=0
Roaming S118=0
Quick Enter to Command S119=1
RTS/DCD Framing (ms) S120=0
DCD Timeout (ms) S121=0
Remote Control S122=0
Secondary Hop Pattern S206=2 (Don’t Care)
Packet Retry Limit S213=2
AT&F3 - Repeater Default Settings
E1, Q0, V1, W0, S0=1, S2=43, S3=13, S4=10, S5=8
DCD &C1 (On)
DTR &D0 (DTR is ignored)
Framing &E0 (Disabled)
Handshaking &K3 (Enabled)
DSR &S1 (On in Data, Off in Command)
Operating Mode S101=4 (Repeater)
Serial Baud Rate S102=7 (9600 baud)
Wireless Link Rate S103=2 (Fast, No FEC) (Set by Master)
Network Address S104=1
Unit Address S105=3
Primary Hop Pattern S106=0
Encryption Key S107=1
Output Power S108=2 (100mW)
Hop Interval S109=4 (Set by Master)
Data Format S110=1 (8N1)
Packet Minimum Size S111=1
Packet Maximum Size S112=43
Packet Retransmissions S113=1
Packet Size Control S114=0
Packet Repeat Interval S115=1
Character Timeout (ms) S116=8
Modbus Mode S117=0
Roaming S118=0
Quick Enter to Command S119=1
RTS/DCD Framing (ms) S120=0
DCD Timeout (ms) S121=0
Remote Control S122=0
Secondary Hop Pattern S206=2
Packet Retry Limit S213=2
AT&F4 -Slave Through Repeater Default Settings
E1, Q0, V1, W0, S0=1, S2=43, S3=13, S4=10, S5=8
DCD &C1 (On)
DTR &D0 (DTR is ignored)
Framing &E0 (Disabled)
Handshaking &K3 (Enabled)
DSR &S1 (On in Data, Off in Command)
Operating Mode S101=3 (Slave)
Serial Baud Rate S102=7 (9600 baud)
Wireless Link Rate S103=2 (Fast, No FEC) (Set by Master)
Network Address S104=1
Unit Address S105=4
Primary Hop Pattern S106=2
Encryption Key S107=1
Output Power S108=2 (100mW)
Hop Interval S109=4 (Set by Master)
Data Format S110=1 (8N1)
Packet Minimum Size S111=1
Packet Maximum Size S112=43
Packet Retransmissions S113=1 (Don’t Care)
Packet Size Control S114=0
Packet Repeat Interval S115=1
Character Timeout (ms) S116=8
Modbus Mode S117=0
Roaming S118=0
Quick Enter to Command S119=1
RTS/DCD Framing (ms) S120=0
DCD Timeout (ms) S121=0
Remote Control S122=0
Secondary Hop Pattern S206=2 (Don’t Care)
Packet Retry Limit S213=2
