9. Technical Specifications
Weight: 460 g (with batteries)
Size: 115 (W) x 182 (L) x 76 (H) mm
Storage temperature: –20 to +50°C
Humidity: 15 to 90% relative humidity maximum
Operation temperature: 10 to 40°C
Display: LCD-Display (Liquid Crystal Display)
Measuring method: oscillometric
Pressure sensor: capacitive
Measuring range:
SYS/DIA: 30 to 280 mmHg
Pulse: 40 to 200 beats per minute
Cuff pressure display range: 0–299 mmHg
Memory: Automatically stores the last 30 measurements
Measuring resolution: 1 mmHg
Accuracy: Pressure within ± 3 mmHg
Pulse ± 5 % of the reading
Power source: a) 4 x 1.5V batteries; LR6, size AA
b) mains adapter 6V DC 600mA (optional)
Cuffs: M-size-cuff (22 - 32 cm) and
L-size-cuff (32 - 42 cm)
Reference to standards: EU directive 93/42/EEC
NIBP - requirements: EN 1060-1 /-3 /-4 & ANSI / AAMI SP10
Technical alterations reserved!
10. www.microlife.com
Detailed user information about our products as well as services can be found at www.microlife.com.
