Micronta 22-214A - Features

FEATURES |
This high-sensitivity MICRONTA
Multitester is designed to measure AC and
DC voltages, DC current and resistance with
accuracy and ease.
The range doubler switch (V-A/2 - V-0-A)
effectively doubles the number of AC and
DC scales available. This means you can
obtain meter readings in the upper half of
the scale, resulting in more accuracy.
The lowest DC ranges - 125mV and 25uA -
are great for solid-state circuit work.
The sensitive 18uA meter movement with
4-1/2” face and mirrored scale makes
accurate reading a simple matter. The meter
scales are in three colors for rapid
identification
The meter circuit incorporates diodes and a
fuse to protect the delicate meter movement
and other internal parts in case of short-
term inadvertent overload or improper
function selection.
A special audible continuity function has
been incorporated. When using this
function, a built-in buzzer will sound when
the circuit continuity is approximately 300
ohms or less
The large, single-knob range/function
control is easy to use and read.
An off position is provided to ensure meter
protection during transit by shunting the
meter movement.
© 1990 Tandy Corporation.
All Rights Reserved.
Micronta and Radio Shack are registered trademarks of Tandy Corporation.
Features
The handle can be flipped around to the CONTENTS
h to-read
aie, support the tester at an easy-to-reai FEATURES -occeccececceccccceccece. 2
} SPECIFICATIONS a. asc canst 5% stcistnutaty . 4
These features combined with rugged CONTROLS AND FUNCTIONS . - 6
design and quality parts ensure you of many SETTING UP YOUR METER ....-..+.-- 9
MAKING MEASUREMENTS ........... 13
years of accurate measurements.
Caution: Permanent damage can occur to
your Multitester from exceeding the
specified limits or attempting to make
measurements with the range switch in
wrong position.
REPLACEMENT OF BATTERY/FUSE ... 28
GOOD METER MEASUREMENT
PRACTICES 34 a quedigzacgea
DURES. NOT FOR COMMERCIAL OR INDUSTRIAL USE.
WARNING : USE EXTREME CAUTION IN THE USE OF THIS DEVICE.
IMPROPER USE OF THIS DEVICE CAN RESULT IN INJURY OR DEATH
FOLLOW ALL SAFEGUARDS SUGGESTED IN THE OWNER'S MANUAL
IN ADDITION TO NORMAL SAFETY PRECAUTIONS IN DEALING WITH
ELECTRICAL CIRCUITS. DO NOT USE THIS DEVICE IF YOU ARE
UNFAMILIAR WITH ELECTRICAL CIRCUITS AND TESTING PROCE-
