LVS-7510 Integrated System Installation and Quick Start Guide for Zebra Printers
LVS-7510 Integrated System Installation and Quick Start Guide for Zebra Printers Page 11 of 16
Step 4: Printer / Media Setup
General Settings
All printer settings required for optimal LVS-7510 function are factory preset. In the case of a printer reset,
however, the following settings are required for correct operation of the unit.
Applicator Settings
To control the start/stop of the print process to handle defective labels and enable peel and present operation,
the applicator port on the printer must be configured as defined here:
Setting Value
APPLICATOR MODE 1
START PRINT SIG
LEVEL MODE for Labels ≥2” Tall
PULSE MODE for labels <2” Tall
Follow these steps to access these settings via the printer web server interface:
1. Connect the printer to your local network via an Ethernet cable.
2. Navigate to the IP address displayed on the printer GUI using a web browser.
3. On the printer landing page, navigate to View and Modify Printer Settings > Advanced Setup.
4. When prompted for a password, enter 1234.
5. Set the desired parameters and click Submit Changes to save changes temporarily. (Cycling power will
restore previous settings.)
6. To save the settings permanently, click Save Current Configuration on the subsequent page.
Energy Star Settings
To prevent the printer from entering sleep mode during the print process and causing it to be unresponsive to the
LVS-7510’s commands, turn OFF Energy Star under the Tools menu in the printer interface.
The subsequent sections cover settings and label routing pertaining to specific printer/verifier configurations.
