Keys and parts
Important: For important info on the safe use of
your device and battery, read “For your safety” and
“Product and safety info” at www.microsoft.com/
mobile/support/ before you take your device into
use. The same info is available in the in-device user
guide. Select
Lumia Help+Tips.
1 Front camera
2Earpiece
3 Volume keys
4 Power/Lock key
5Microphone
6 Micro-USB connector
7 Audio connector AHJ 3.5 mm
8 Camera lens
9 Camera flash
10 Loudspeaker
11 Antenna area
Some of the accessories mentioned in this user
guide, such as charger, headset, or data cable, may
be sold separately.
Avoid touching the antenna area while the antenna
is in use. Contact with antennas affects the
communication quality and may reduce battery life
due to higher power level during operation.
