Microsoft Surface Go 2 User Manual

M1154224-001
16
4. Install hinge screws - Flip the kickstand up to approximately 90° such that the threaded holes of the
kickstand align with the mounting holes of the hinge. Install the hinge screws in the order shown below with
the 3IP (Torx-Plus) driver. Ensure screws do not fall into the hinge opening. Use your finger to hold the back
of the kickstand behind the hinge while installing the screws until they are fully seated. Verify the kickstand
is properly aligned and seated in the hinges, then tighten the screws an additional ~quarter turn (~90°).
5. Final inspection Kickstand installation - Fold the kickstand down and peel off protective plastic from the
kickstand and logo if present. Verify the side edges of the kickstand are aligned with the midframe walls and
that there are no obvious steps/gaps between the kickstand and the IBC. Wipe the device thoroughly
(including under the kickstand) with the microfiber cloth to remove all fingerprints.
2
4
1
3
HOLD

Microsoft Surface Go 2 Specifications

General

HD type	-
Pixel density	220 ppi
Display diagonal	10.5 \
Touchscreen type	Capacitive
Display resolution	1920 x 1280 pixels
Native aspect ratio	3:2
Tjunction	100 °C
Processor cache	2 MB
Processor cores	2
Processor model	4425Y
System bus rate	4 GT/s
Processor family	Intel® Pentium®
Processor threads	4
Processor codename	Kaby Lake
Processor frequency	1.7 GHz
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Processor operating modes	64-bit
PCI Express configurations	1x4, 2x2
Supported instruction sets	SSE4.1
Thermal Design Power (TDP)	6 W
Thermal Monitoring Technologies	Yes
Internal memory	4 GB
Internal memory type	LPDDR3-SDRAM
Storage media	eMMC
Compatible memory cards	MicroSDXC
Internal storage capacity	64 GB
Graphics card	UHD Graphics 615
Audio system	Dolby Audio Premium
Speaker power	2 W
Rear camera type	Single camera
Rear camera flash	No
Video recording modes	1080p
Maximum video resolution	1920 x 1080 pixels
Rear camera resolution (numeric)	8 MP
Front camera resolution (numeric)	5 MP
SIM card type	NanoSIM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
HDMI ports quantity	0
Docking connector type	Microsoft Surface Connector, Microsoft Surface Cover
Headphone connectivity	3.5 mm
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
Color name	Platinum
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Housing material	Magnesium
Platform	Windows
Trial software	Microsoft 365 Family
Operating system installed	Windows 10 Home in S mode
Battery capacity	- mAh
Battery life (max)	10 h
Processor ARK ID	192786
Processor socket	BGA 1515
AC adapter power	24 W
Repairability index	3.5

Weight and Dimensions

Depth	8.3 mm
Width	245 mm
Height	175 mm
Weight	544 g
