Table 1. Surface Hub 2S port and keypad component reference
USB 3.0 Port
• Use as a walk-up port for plugging in peripherals such as thumb-
drives. Guest ports are located on each side of the device (4).
•
NOTE: This is the recommended port for connecting an external
camera. Additional camera mount features are incorporated into the
design to help support retention of attached cameras.
• NOTE: TouchBack and video ingest are not supported on these ports.
Type C
• 15 W Port
(5V/3A)
100-240V input
Connect to standard AC power and Surface Hub 2S will auto switch to
the local power standard such as110 volts in the US and Canada or
220 volts in the UK.
NOTE: When the AC cord is plugged in, the system remains in an off
state in which only the system management controller (SMC), real
time clock (RTC), and keypad are running.
24V DC input port
Use for connecting to mobile battery.
Xbox1 Dual
barrel to
Anderson
connector
1000/100/10 BaseT
Use for providing a continuous connection in a corporate
environment and related scenarios requiring maximum stability or
capacity.
USB 3.0 Port
Use as a walk-up port for plugging in peripherals such as
thumb-drives.
Type A
7.5 W Port
(5V/1.5A)
USB 3.0 Port
Use as a walk-up port for connecting external PCs and related devices
or plugging in peripherals such as thumb-drives.
NOTE: This is the recommended video input port, supporting both
TouchBack and InkBack.
Type C
18 W Port
(5V/3A,
9V/2A)
HDMI 2.0, HDCP 2.2 /1.4
Use for multiple scenarios including HDMI-to-HDMI guest input.
