Microsoft Surface Hub 2S - Page 12

7
Microsoft confidential internal and/or partner use only
Key
Component
Description
Key
parameters
⑧
Mini
DisplayPort
out
DisplayPort 1.2 output
Use for video-out scenarios such as mirroring the Surface Hub 2S
display to a larger projector.
Mini
DisplayPort
⑨
Source
Use to toggle among connected ingest sources — external PC, HDMI,
and DisplayPort modes.
n/a
⑩
Volume
Use +/- to adjust audio locally on the device.
NOTE: When navigating to the brightness control, use +/- on the
volume slider to control display brightness.
n/a
⑪
Power
Power device on/off.
Use also to navigate display menus and select items.
n/a
Figure
2.
Rear facing view of wireless, audio, & related components
