Microsoft Surface Hub 2S - Installation and Mounting Standards

11
Microsoft confidential internal and/or partner use only
Specifications
Microsoft Surface Hub 55”
Microsoft Surface Hub 2S 50”
• NFC reader
• Miracast enabled
• Miracast Display
Camera
• Two 1080p front-facing
cameras
• 100-degree horizontal field of
view
• One Surface Hub 2S Camera
• 90-degree horizontal field of view
4K, USB-C connection
• Anti-flicker, face-based auto
exposure, up to 30 frames per
second
Audio
• 4-element microphone array
• Two front-facing stereo
speakers
• Full band 8-element MEMS
microphone array. (MEMS
microphones respond equally to
sounds coming from any direction.)
• Full range front facing 3-way stereo
speakers
Accessories
• Two powered, active pens
• One wireless all-in-one
keyboard
• One Microsoft Surface Hub 2 Pen
(active)
• One Surface Hub 2 Camera
Sensors
• Two passive infrared presence
sensors
• Ambient light sensors
• Doppler occupancy sensor
• Accelerometer
• Gyroscope
Power saving feature
• S3 Sleep
• Connected Standby
Ports
• Four USB-A (Keyboard, Side,
2x Aux)
• USB-B (TouchBack)
• DisplayPort video input
• HDMI video input
• VGA + audio input (3.5mm)
• DisplayPort video output
• Audio output (3.5.mm)
• RJ45 Gigabit Ethernet
• Serial Port
• USB-A
• Mini-DisplayPort video output
• HDMI video input
• USB-C with DisplayPort input
• Four USB-C (on display)
• RJ45 Gigabit Ethernet
Other features
Microsoft Surface Hub 55”
Microsoft Surface Hub 2S
PEN battery/charging
• Non-removable
• Rechargeable via pen dock
• Removable AAA battery
• Customer replaceable
Multiple pen use
• Three pens
• One pen
Pen dock
• Located on each side of
display
• Pen uses magnetic attachment
available on all 4 sides of bezel
Pen button and eraser
• Active pen, no button, tail
eraser
• Active pen, barrel button, tail
eraser
• Connector type – Bluetooth
4.0
