Other features
Microsoft Surface Hub 55”
Microsoft Surface Hub 2S
Wireless keyboard
• Keyboard included
• Keyboard not included
Speakers/microphone
• Located in wings
• Integrated into display
USB TouchBack port
• USB-B
• USB-C
Wired connect inputs
• DisplayPort
• HDMI
• VGA +3.5 mm audio input jack
• HDMI+USB-C (for TouchBack)
• USB-C (video, audio,
TouchBack)
Bypass mode via source selection
• DisplayPort
• HDMI
• VGA
• HDMI
• DisplayPort (via USB-C
connection)
Bypass mode TouchBack
• Via USB-B connection
• Not available
DisplayPort output
• Standard DisplayPort
connection
• Mini DisplayPort connection
DisplayPort image (duplicate)
• Always enabled
• Image available when source
is changed to DisplayPort,
HDMI, or VGA
• Use keyboard command:
Win+P > Duplicate
• No image available when
source is changed to
DisplayPort or HDMI
Audio output
• 3.5 mm audio jack
• USB-A or USB-C (via adapter
or external converter cables)
Replacement PC Mode (disable
internal PC)
• Available via switch on
videoboard
• Not available
Physical buttons
• Power, volume, source,
brightness
• Power, volume, source
Customer replaceable SSD
• 128 GB 2.5” SATA SSD and
sled
• 128 GB M.2 NVMe
• Located within compute
module
• NOTE: NVMe is a protocol that
lets data be read and written
via PCI-E)
Replaceable compute module
• Requires removal from
stand/wall and disassembly of
device
• Removal from wall/stand not
required
• Cartridge design: single screw,
removed from bottom of
device
OS image recovery methods
• Reset from OS (via settings)
• Cloud recovery
• Surface Hub recovery tool
• Physical SSD replacement
• Reset from OS (via settings)
• Cloud recovery tool
• Bare metal reset
• Physical M.2 replacement
Room controller
• Via serial port, via ASCII
controls
• None for Hub 2S (planned for
future release).

Microsoft Surface Hub 2S Specifications

General

Display Size	50 inches
Resolution	3840 x 2560
Aspect Ratio	3:2
Touch	Multi-touch
Processor	Intel Core i5
RAM	8 GB
Storage	128 GB SSD
Operating System	Windows 10 Team
Graphics	Intel UHD Graphics 620
Speakers	Front-facing stereo speakers
Ports	USB-C, USB-A, HDMI
Wireless Connectivity	Wi-Fi 5, Bluetooth 5.0
Camera	4K camera
Microphones	Far-field microphone array
Weight	28 kg
Dimensions	741.9 mm x 1097.7 mm x 76.1 mm
Mounting Options	VESA mount
