Microsoft Surface Hub 55" - Page 6

4
M6 nuts (6 each)
Torque: 8-10 N.m (5.9-7.4 ft-lbs)
M6x12 screw (4 each): stand assembly screw
Torque: 6-8 N.m (4.4-5.9 ft-lbs)
M6 washer (4 each)
Stand assembly washers
Toggle bolts (6 each)
Screw (4 each): hanger bar screw
Surface Hub 55”: M6x12mm
Torque: 6-8 N.m (4.4-5.9 ft-lbs)
Surface Hub 84”: M8x12mm
Torque: 15-17 N.m (11-12.5 ft-lbs)
K
